HPL 550w lamp 77v USHIO HPL-550/77X 550 watt Long Life halogen bulb

Ushio HPL-550/77X+, JS77V-550WX 550 Watt 77 Volt tungsten halogen, long life HPL series

The High performance Ushio 1000669 HPL-550/77X+, JS77V-550WX, 200 Hours lamp has been redesigned to be the most powerful HPL ever. It's ultra-compact filament geometry now improves the optional efficiency of your ETC Source Four fixtures to produce up to 20% more fixture lumens. That's up to 20% more light from the same fixture as compared to the old lamp design.

Features:
- Abbreviation Name: HPL-550/77X+, JS77V-550WX, 200 Hours
- Description 2: 550W 77V
- Base: G9.5 2-Pin w/ Heat Sink
- Bulb Type: Halogen Bulbs
- Color Rendering Index (CRI): 100
- Color Temperature (K): 3050K
- MOL (in): 2.38
- Diameter (in): 0.72
- Light Center Length (in): 2.38
- Filament: 4-C8
- Lamp Finish: Clear
- Luminous Flux (LM): 12160
- Rated Life (Hours): 2000
- Shape: T6
- Voltage: 77V
- Wattage: 550W

Abbreviation Name	HPL-550/77X+, JS77V-550WX, 200 Hours
Description 2	550W 77V
Base	HT/SNK
Bulb Type	Halogen Bulbs
Color Rendering Index (CRI)	100
Color Temperature (K)	3050K
MOL (in)	2.38
Diameter (in)	0.72
Light Center Length (in)	2.38
Filament	4-C8
Lamp Finish	Clear
Luminous Flux (LM)	12160
Rated Life (Hours)	2000
Shape	T6
Voltage	77V
Wattage	550W

Manual:

HPL Cross Reference
Ushio 1000669 HPL-550/77X+
