4 in. White Recessed Square Gimbal Trim for MR16 Bulb

NICOR’s quality constructed 4-inch square adjustable gimbal trim creates a simple and attractive finished look for any room. The 14023 series gimbal trim is designed for MR16 light bulbs rated up to 50-Watts. The 14023 features a 30° vertical tilt to help light up those hard to light areas, fireplaces, art, or collectibles. The 14023 installs to fit standard 4-inch recessed housings using tension clips (included) for installation. The 14023 measures 4.875-inches in diameter with a gimbal aperture of 2-inches Use with any of NICOR’s 4-inch recessed housings for a perfect match, or use with an existing 4-inch recessed housing. The 14023 is protected by NICOR's 1 Year Limited Warranty.

Features:
- Requires one MR16 bulb rated up to 50-Watts Max. (not included)
- Designed to fit 4-inch recessed housings
- Trim measures 4.875-inches in diameter with a 2-inch aperture
- Includes Tension Clips for a Fast and Secure Installation
- Comes ready to install. No extra parts required.

Model Number	14023WH
Size (in.)	4
Product Color	White
Finish	Powder Coat
Bulbs Included	No
# of Bulbs Required	1
Recommended Bulb Type	MR16
Bulb Wattage (Max)	50
Listings/Certifications	ETL Intertek Listed UL 1598 Dry-Location
Warranty (Years)	1 Year Limited

Manual:

Nicor 14023WH Data Sheet
