EMB Series 25W Universal LED Emergency Battery Backup Driver

The NICOR EMB250 is an LED emergency driver designed for factory or field installations that enables normal and emergency operation of a switched or non-switched LED fixture. During a power failure, the EMB250 activates emergency mode to maintain consistent output wattage to the fixture without light degradation for a 90 minute duration. The EMB250 contains a 6000mAh Lithium Iron Phosphate battery, charger, test switch, and converter circuit in a powder-coated steel finished housing. Protected by NICOR 3 Year Limited Warranty.

Features:
- Rated for Plenum, Damp Location, and IC Rated Fixtures
- Capacity: 6000mAh Lithium Iron Phosphate
- Emergency Mode: 90 Minutes (Min.) @ 25W
- Input Voltage: 120~277VAC (50/60Hz)
- Input Current: 100mA Max

Size (in.)	10
Product Color	Orange
Finish	Powder Coat
Wattage	25w
Voltage	120-277V
Warranty	3 Year Limited Warranty

Manual:

EMB250-10-UNV Data Sheet
