HPL 550w lamp 77v USHIO 550 watt HPL-550/77V halogen bulb

Ushio HPL-550/77V+, JS77V-550WC 550W/77V, tungsten halogen, HPL Lamp

The High performance Ushio 1000668 HPL-550/77V+, JS77V-550WC, 300 Hours lamp has been redesigned to be the most powerful HPL ever. It's ultra-compact filament geometry now improves the optional efficiency of your ETC Source Four fixtures to produce up to 20% more fixture lumens. That's up to 20% more light from the same fixture as compared to the old lamp design.

Features:
- Abbreviation Name: HPL-550/77V+, JS77V-550WC, 300 Hour
- Description 2: 550W 77v
- Base: G9.5 2-Pin w/ Heat Sink
- Bulb Type: Halogen Bulbs
- Color Rendering Index (CRI): 100
- Color Temperature (K): 3250K
- Diameter (in): 0.72
- Filament: 4-C8
- Lamp Finish: Clear
- Luminous Flux (LM): 16170
- Maximum Overall Length (in): 4.09
- Light Center Length (mm): 60.3
- Rated Life (Hours): 300
- Shape: T6
- Voltage: 77V
- Wattage: 550W

Abbreviation Name	HPL-550/77V+, JS77V-550WC, 300 Hour
Description 2	550W 77v
Base	HT/SNK
Bulb Type	Halogen Bulbs
Color Rendering Index (CRI)	100
Color Temperature (K)	3250K
Diameter (in)	0.72
Filament	4-C8
Lamp Finish	Clear
Luminous Flux (LM)	16170
Maximum Overall Length (in)	4.09
Light Center Length (mm)	60.3
Rated Life (Hours)	300
Shape	T6
Voltage	77V
Wattage	550W

Manual:

HPL Cross Reference
Ushio 1000668 550W 77V HPL Halogen Bulb
