NICOR 2 in. Square LED Downlight 4000K Cool White 694Lm with White Trim

IMPORTANT - Requires a NICOR 2-inch LED Recessed Housing - NOT INCLUDED. See Related Products below for compatible Housing

NICORs D-Series luminaries offer a comprehensive family of LED down light fixtures that complement one another no matter your design space needs. The new 2-inch family packs a punch with its small, elegant design along with its high lumen output. Not only does this family work perfect for accent and task lighting, but the lighting output allows you to bring general ambient lighting into a space with a very small, architectural exposure. From LED color rendering and trim finishes to fixture performance, this series is a perfect choice for commercial, retail, institutional, and residential applications.

Features:
- IMPORTANT - Requires a NICOR 2-inch LED Recessed Housing
- Energy Star Rated, Uses less than 10 Watts
- Dimmable down to 10%
- Uses Standards House hold Voltage (120 Volts)
- For IC-Rated, Airtight New Construction application, use Housing Model 12200A-LED

Application:
- Cast aluminum trim routes heat away from electrical components
- This downlight is intended for use with NICOR 2 LED housings

Optical System:
- TIR optic provides smooth, uniform light
- Beam spread options available: 37(standard)

Electrical:
- COB with greater than 90 CRI and an R9 greater than 50
- Dimmable to 10% with most standard triac dimmers
- Operating temperature rating of 0F to 120F (-18C to 49C)
- Lifetime rated for greater than 35,000 hours
- LM-79, LM-80 testing performed in accordance with IESNA standards
- Fixture driver located on housing

Installation:
- Only compatible with NICORs 2 recessed housings: Available in remodel, new construction, and IC/ Airtight new construction
- Quick and easy installation with a snap-in IDEAL connector and friction clip mounting system

Size (in.)	2-inch
Product Color	White
Finish	Powder Coat
Light Source	LED
Wattage	8.9w
Wattage Equivalent	60w Equiv.
Voltage	120v
Lumen Output	687lm
Lumens Per Watt	77.2lm
Color Temperature (CCT)	4000k
Color	Cool White
CRI	91.8
R9 Value	>50
Dimmable	Yes Dimmable
Dimming Type	TRIAC
Operating Temperature	0F to 120F (-18C to 49C)
Listings/Certifications	UL Listed, cUL Listed, Title 24, Energy Star, Wet-Location
Warranty	5 Years Limited

Manual:

DQR2-10-120-4K-WH Data Sheet
DQR2-10-120-4K-WH Installation Manual
