NICOR LED Emergency Exit Sign Color Combo With Remote

The ECL1-Select LED Emergency Exit Sign Combo features field-selectable red and green lettering. With included templates for both colors, simply install the slide color you need and flip the LED switch inside to match. The ECL1 is offered in white and features a universal mounting bracket for simple installation anywhere, and 90-minute emergency operation with integrated test button. This series is available in both a standard and remote-capable option to use with Remote Heads (2 max), available separately. The ECL1-Select is the ideal low-energy choice for multifamily, commercial, and retail settings.

Features:
- Injection molded thermoplastic ABS housing
- UL-94V-0 flame rating - Flame Retardant
- Field Selectable Red and Green LED light and lettering
- 6-in Letter height
- Supplied with faceplates for single or double face configuration
- 120/277V dual voltage operation
- LED indicator light & push-button test switch
- 90 Min capacity on emergency mode
- Remote Capability up to 3W (1.5W per remote head)
- 3.6V per remote head
- Damp location rated

Model Number	ECL120UNVWHS2R
Product Type	LED Exit Sign Red or Green Text (Selectable) with Remote Head
Size (in.)	12-in
Product Color	Red|Green
Finish	White
Wattage	4w
Voltage	120-277v
Lumens	386L
Application	Residential or Commercial
Bulb Type	LED
Bulbs Included	Yes
Listings/Certifications	UL Listed, cUL Listed, IC-Rated, Damp Location
Warranty	1 Year Limited

Manual:

ECL120UNVWHS2R Data Sheet
