OSRAM XBO 3000W DHS OFR, XBO DHP for Digital Projection Lamp

OSRAM XBO 3000W DHS OFR, XBO DHP for Digital Projection Lamp

SKU: 69462

$1,60499 ~~$2,083.99~~ USD

Sorry, this product is temporarily out of stock, please check Related Products below, or use the email for stock updates

Description

Osram XBO 1200W/DHP OFR, XBO DHP for Digital Projection Lamp Product features
- Short arc with very high luminance for brighter screen illumination
- Constant color temperature of 6,000 K throughout the entire lamp lifetime
- Easy to maintain
- High arc stability
- Instant light on screen thanks to hot restart function
- Wide dimming range
Areas of application
- Digital Projection
- Film Projection
- Spotlights
- Searchlights
- Solar Simulation

Specs

Nominal current	105 A
Current control range	77.113 A
Nominal Wattage	3000.00 W
Nominal Voltage	29.0 V
Diameter	60.0 mm
Length	342.0 mm
Length with base excl. base pins/connection	302.00 mm
Light center length (LCL)	145.0 mm
Cable/wire length, input side	155 mm
Cable length	155.0 mm
Product weight	591.00 g
Electrode gap cold	6.0 mm
Max. permitted ambient temp. pinch point	230c
Lifespan	1500 h
Service Warranty Lifetime	2000 h
Base anode (standard designation)	SFaX27-9.5
Base cathode (standard designation)	SFa27-7.9
Cooling	Forced
Burning position	s15/p15
EAN	4062172030540
Unit	VS
Piece	1
Dimension l x w x h	500mm x 204mm x 204mm
Weight	1521.00g
Volume	20.81dm3
CA Prop 65	Yes
CA Prop 65 Material	Mercury
