Robertson SP79P-A-V1 Magnetic CFL Ballast 120v

Magnetic Preheat Start Ballast, 120Vac, 60Hz, for 1 CFT9W/G23 Lamp.

PERFORMANCE:
- Electromagnetic reactor type ballast
- Preheat start
- Series operation
- Normal power factor
- Clamped core and coil
- Sound rated A
- Meets ANSI C82.1

APPLICATION:
- Maximum case temperature: 194F/90C
- Maximum ambient temperature: 104F/40C
- Minimum starting temperature CFL: 32F/0C
- Minimum starting temperature Linear: 50F/10C
- Remote mounting: 10ft.
- Side Lead

SAFETY:
- UL/935 (Class P, Type 1 outdoor) listed
- CSA certified (cUL)
- Automatic reset thermal protector
- No PCB's
- RoHS Compliant

Ballast Type	Electromagnetic
Starting Method	Preheat
Input Voltage	120VAC+5%-10%
Lamp Connection	Series
Input Frequency	60 Hz.
Unit Color	White

- Actinic BL PL-S 9W
- HNS S 9 W G23
- TUV 5W
- TUV PL-S 5W
- 21062 Osram HNS S 9 W G23

Manual:

SP79P-A-V1 Data Sheet
