Robertson SS20604 WT /A V2 Magnetic Preheat Ballast 120V

Magnetic Preheat-Self Start Ballast (for 4 Pin Lamps), 800mA nominal lamp current, Input voltage of 120Vac, for 1 35W Lamp with a 14" lamp length, 60Hz, terminal connector.

PERFORMANCE:
- Electromagnetic reactor type self start ballast
- Series operation
- Normal power factor
- Encased & potted
- Sound Rated A
- Meets ANSI standard C82.1

APPLICATION:
- Maximum case temperature: 194F/90C
- Maximum ambient temperature: 140F/60C
- Minimum starting temperature: 50F/10C
- Lamp starts: >6,000 starts
- Remote mounting: 10ft.

SAFETY:
- UL935 Listed
- Class P, Type HL, Type 1 Outdoor
- CSA/C22.2 certified
- Automatic reset thermal protector
- No PCB's

Ballast Type	Electromagnetic
Starting Method	Preheat Self Start
Input Voltage	120VAC+5%-10%
Lamp Connection	Series
Input Frequency	60 Hz.

- GPH287T5L/HO
- GPH287T5VH/HO
- GPH330T5HO
- GPH356T5HO
- GPH406T5L/HO
- GPH436T5L/HO
- GPH436T5L/HO/4PSE
- GPH436T5VH/HO
- GPH508T5L/HO/4P

Manual:

SS20604-WT-A-V2 Data Sheet
