Satco 100w LED HID Replacement ColorQuick CCT Selectable Mogul Base 277-480V

Satco SKU: S23168
$17895 $295.99 USD
1581 in stock


Satco 100 watt LED lamp is the lamp of choice for large scale applications. Illuminate gymnasiums, warehouses or any other venues with high ceilings requiring light output. This CCT selectable map delivers 50,000 hours of clean, energy saving light.

- MOL: 10.46 inches, MOD: 5.12 inches
- Corncob Shape
- White Finish
- Mogul Extended Base
- 300 degree beam spread
- Rated for 50,000 hours
- CCT Selectable
- 5 year limited warranty
- Damp rated for indoor and outdoor use


Watts 100W
HID Equivalent 400W
Volts 277V-480V
Shape Corncob
Base Extended Mogul
ANSI Base EX39
Finish White
CCT (Kelvin) 3000K/4000K/5000K
Temperature Warm to Cool White
CRI 80
Lumens 13000L/14000L/13500L
Beam Spread 300
Dimmable Yes-Dimmable
Hours Rated 50000
Technology Corncob LED
Ballasting Requirements Ballast Bypass
Operating Frequency 50-60 Hz
Power Factor >0.9
Operating Temperature -30C (-22F) to a maximum of +45C (+113F)
MOL 10.46
MOD 5.12
Weight (lb.) 3.19
Material Plastic
Housing Color Dark Gray
Additional Information
Rated For Enclosed Fixture Yes
Warranty 5 Year Limited
Safety Listing cUL - Classified; cRUus - Recognized Component
Location Rating Damp
Energy Star No
CA T20 / T24 Rationale Lawful for sale
California Status Lawful for sale in California
RoHS Compliant Yes
FCC Compliant Yes
DLC Approved Yes
