Sunlite 9w LED PLV Plug and Play G24q Base 3500K Bulb - Ballast Dependent

Replace your 26 watt compact fluorescent PL bulbs with energy efficient 9 watt LED plug and play bulbs from Sunlite. LED Technology means flicker free light that comes on instantly with no warm-up time and no buzzing like CFL bulbs. Provides up to 50,000 hours of energy efficient light so youll have to replace difficult to access bulbs less often. Unlike CFL bulbs these LED lamps contain no hazardous chemicals. They are UL Listed for damp location installation. These 4-Pin base (G24q) plug and play bulbs do not require a ballast bypass. For use with electronic ballasts only. See manufacturer�s website for a complete list of compatible ballasts.

FEATURES:
- UPGRADE TO LED - Replace your 26 watt compact fluorescent PL bulbs with energy efficient 9 watt LED plug and play bulbs from Sunlite. They feature a 4-Pin base (G24Q) and are instant on at full brightness with no buzzing or flickering. Ideal for use in recessed lighting, lamps or any compatible fixture.
- PLUG AND PLAY - These bulbs are direct replacements for PL fluorescent bulbs with no bypass required. For use with electronic ballasts only. See manufacturer�s website for a complete list of compatible ballasts.
- ENERGY EFFICIENT - These 9 watt LED bulbs are direct replacements for 26 watt CFL bulb. 950 Lumen output with a color temperature of 3500K (neutral white). Low annual operating costs of only $1.08. (Based on 3 Hours/Day at $0.11/kWh)
- LONG LIFE SPAN - Provides up to 50,000 hours of energy efficient light means youll have to replace difficult to access bulbs less often. Makes commercial and residential fixtures virtually maintenance-free.
- A SAFER CHOICE - Unlike CFL bulbs these LED lamps contain no hazardous chemicals. They work with your existing ballasts so no special wiring or modifications are needed. They are DLC Listed for quality and efficiency.

General Characteristics
Base	G24q
Shape	PLV
Finish	White
Rated Life	50,000 hrs
Average Life Span Years	45
Dimmable	Non-Dimmable
Electrical Characteristics
Watts	9
Equivalent Wattage	18 equiv
Volts	120-277
Power Factor	0.9
Temperature	-20-45?
Light Characteristics
Lumens	950
CRI	82
Color Temperature Kelvin	3500K
Color	Neutral White
Beam Angle	150 deg
Product Dimensions
MOL	4.66
Weight	0.280
Product Data
Safety Rating	UL Listed
Ul rated enclosed fixtures	Yes
Dlc	Yes
UPC	653703882147
Abbreviation	PLV/E/LED/IS/9W/35K/V2
Warranty	5 Years Limited

Manual:

88214-SU Data Sheet
