USHIO SM-H2000 50W 22.8V G6.35 Base Incandescent Scientific Medical Light Bulb

SM-H2000 Hanalux Siemens Ushio Scientific & Medical Lamps The SM-H2000 is a halogen lamp with 50watt, 22.8Volt and G6.35 base

Features:
- ANSI Code: SM-H2000
- Wattage: 50W
- Voltage: 22.8V
- Base: G6.35
- Average Rated Life: 700 hours

CROSS REFERENCES
- OSRAM 54056 64650
- Ushio 8000325 SM-H2000

SM-H2000 bulb is used in following equipment:
- Dr. Mach M3F
- Hanalux / Siemens 15282
- Hanalux / Siemens 561 152 82
- Hanalux / Siemens H2000

Prod. ID / Ansi code	SM-H2000
Description	SM-H2000,Sci/Med Lamp
Description 2	50W 22.8V G6.35
Item Type	Incandescent
Base	G6.35
Voltage	22.8v
Wattage	50w
Bulb finish	CLEAR
Color Temp (k)	3000
Filament	CC-8
Mean Lumens (lm)	1100
Life (hr)	700
Diameter (mm)	10.5
MOL (mm)	42
Lgiht Center Length (mm)	30

Manual:

Ushio 8000325 SM-H2000
